Multi Layer Coextrusion Film Blowing Machine (5 Layers)

Five layer coextrusion film blowing machine production line produced by our company can meet the vast majority of film production applications in the industry, and can be used to produce symmetrical and asymmetric barriers. The scope of application includes: oil packaging, milk bags, lining of solid containers, vacuum packaging, etc.

Multi Layer Coextrusion Film Blowing Machine (5 Layers)

Main machine: All main machines of adopt screws that feature excellent hardness and wear resistance. It can still plasticize a large number of particles under the environment of high speed and high pressure.

Die-head: 5-layer co-extrusion blown film machines adopts a special structure with 5-layer cone.We are sure that after a high degree of polishing and coating, each runner has the ability to clean itself under the high pressure and high speed scouring of high-speed screw.

Advanced control system : five layer coextrusion film blowing machine production line has advanced automation functions, such as centralized feeding, batching, gram weight control, IBC internal cooling, automatic thickness control and full-automatic central winding. All integrated in touch screen integrated control. The operation is more simple and the production efficiency is improved.

Model	5SJ-G1500
Film Tube Width	1500mm
Material	HDPE, LDPE, LLDPE, EVA, Nylon etc.
Air Ring	Double Lip Air ring
Screw Diameter	ф55×4 ф60×1
Screw Ratio L/D	30：1
Material cooling	Water Cooling
Main Motor Power	30Kw×4 37Kw×1
Capacity(Single)	300kg / h
One side film thickness	0.03 - 0.2 mm
Total Power	200kw
Machine size(cm)	10 x 6.0 x 12.5 m
Machine Weight	16T
Power Voltage	220V,380V,440V,480V(Customized based on request,For example: USA 480V 60Hz, Mexico 440V/220V 60Hz, Saudi Arabia 380V 60Hz, Nigeria 415V 50Hz...)
Machine Working Time	24 hours * 7 days
Warranty	1 year
Technical Assistance	Engineers available to service machinery overseas

All of our machines with 1 year guarantee.

Our machines are well favoured by customers due to easy operation, perfect performance, easy maintenance good & prompt after sale service.
If you need installment or training service,we can send engineer to your country,
help you install machines,training your workers to use machine(you need pay double way air tickets,salary,food,hotel for our engineer).

Multi Layer Coextrusion Film Blowing Machine (5 Layers)

Install machines in Saudi Arabia.

If you buy one container machines,we will pack machine with stretch film and loading container directly (FCL full container load).

Multi Layer Coextrusion Film Blowing Machine (5 Layers)

If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.

Multi Layer Coextrusion Film Blowing Machine (5 Layers)

Our Main parts cooperator as following brand,but standard parts all made from China.

Multi Layer Coextrusion Film Blowing Machine (5 Layers)

How To Find Polyethylene For Blown Film Extrusion?
Extrusion Film Extrusion use Polyethylene,such as

Low Density Polyethylene(LDPE),High Density Polyethylene(HDPE) and Linear Low Density Polyethylene(LLDPE),Polypropylene(PP).
Below are big brand material supplier in the world,they open office all over the world,you can check them in local market.
1.Sabic Saudi Basic Industries Corporation
2.ExxonMobil Chemical Company
3.Dow Chemical Company
