High Speed Single Plate Open Cam Paper Cup Machine
High Speed Single Plate Open Cam Paper Cup Machine
High Speed Single Plate Open Cam Paper Cup Machine

High Speed Single Plate Open Cam Paper Cup Machine

High Speed Single Plate Open Cam Paper Cup Machine. Paper Cup Size: 2 ~16 OZ (Mould exchangeable), Maximum Cup Height:136mm, Maximum Bottom width :72mm. Rated Speed: 70-85pcs/min ( Speed affected by cup size, paper quality & thickness) For example: 9OZ, 280GSM paper cup Stable running speed 80pcs/min

Main Technical Variables:

Model

ZB-OCM12



High Speed Single Plate Open Cam Paper Cup Machine

Paper Cup Size:

2 ~16 OZ (Mould exchangeable)

Maximum Cup Height:136mm ,

Maximum Bottom width :72mm

Rated Speed:

70-85pcs/min    ( Speed affected by cup size, paper quality & thickness)

For example: 9OZ, 280GSM paper cup Stable running speed 80pcs/min

Raw Material:

Only one-side PE coated paper ( Popular for Hot drink cups )

One or Two side PE coated Paper
(Popular for Hot and Cold drink Cups)

Suitable paper weight:

140~250gsm

140-350gsm

Power Source:

380V, 50HZ, 3PH ( It can change according client requirement)

Total Power:

6.5 KW

8.5 KW

Total Weight:

1800KGS

Pack Size (L*W*H)

2100x970x1700mm (Machine Size),

1250x860x1860MM(Counting device Size)

Working Air Source:


No need provide Air

Air pressure:0.4Mpa;
Air Out-put:0.6m³/minute
Need to buy Air Compressor(by user)

Cup Side Welding:

Copper Heater

Ultrasonic Heater

Cup Bottom Heating:

Heater Knurling

1side PE paper by heater knurling;

2side PE paper by cool device (circle

water) knurling

Cup Bottom Knurling:

Heater Knurling (if use single PE coated paper)

High Speed Single Plate Open Cam Paper Cup Machine

High Speed Single Plate Open Cam Paper Cup Machine

High Speed Single Plate Open Cam Paper Cup Machine

High Speed Single Plate Open Cam Paper Cup Machine



Grouped equipment:  Plastic Bag Packing Machine

Model

KD-X450



Plastic Bag Packing Machine

Option Row

Single Row

Packaging film thickness

0.018-0.06mm

Max. film width

430mm

Bag length

150-600mm

Cup diameter

40-100mm

Cup quantity

10-100pcs/min

Packing speed(According material)

15-60 Bag/min

Machine Size

2200x1000x1400mm

1300x1100x2200mm





If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load(LCL).

High Speed Single Plate Open Cam Paper Cup Machine

Our Main parts cooperator as following brand,but standard parts all made from China.

High Speed Single Plate Open Cam Paper Cup Machine
