Double Colors Film Blowing Machine
Double Colors Film Blowing Machine
Double Colors Film Blowing Machine

Double Colors Film Blowing Machine

Two colors film blowing machine ,can use low density polyethylene (LDPE), high density polythylene (HDPE) to produce high quality film,machine equip two extruder,mix two different colors in die head,to produce two colors film, Which are widely used for table cover film,two colors T-shirt bag,two colors film and other products,etc.

Optional Equipments:

1)Auto Loader
2)Air Compressor
3)Double Side Winder(Back to back winder)
4)Up and Down
5)Embossing Cylinder
6)Air Shaft
7)Masterbatch Dosing device
8)Automatic Winder Changer
9) Corona treatment



Double Colors Film Blowing Machine

Double Colors Film Blowing Machine
Double Colors Film Blowing Machine



Model

SJ-45 * 2 (600mm)

SJ-50 * 2 (800mm)

Diameter of Screw

Φ45* 2

Φ50 * 2

Max. Width of Folded Film(mm)

100-600

200-800

Single-face Thickness of Film(mm)

0.01-0.10

0.01-0.10

Max. Extrusion(kg/h)

35-40

50

Power of Main Motor(kw)

18.5

18.5

Power of Traction Motor(kw)

1.1

1.1

Heating Power(kw)

18

18

Overall Dimensions(mm)

4800* 1900* 4100

5500* 2100* 4700

Weight(T)

2.2T

2.5T

Material

LDPE,HDPE,recycle material

Film Color

Transparent,Black,Red,White,blue…bag color changed by masterbatch

Usage

packing film,table cover,shrink film,plastic bag,water bag

Power Voltage

220V,380V,440V,480V(Customized based on request,For example: USA 480V 60Hz, Mexico 440V/220V 60Hz, Saudi Arabia 380V 60Hz, Nigeria 415V 50Hz...)

Material Core Diamater

76mm

Machine Working Time

24 hours * 7 days

Warranty

1 year

Technical Assistance

Engineers available to service machinery overseas

※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.



All of our machines with 1 year guarantee.

Our machines are well favoured by customers due to easy operation, perfect performance, easy maintenance good & prompt after sale service.
If you need installment or training service,we can send engineer to your country,
help you install machines,training your workers to use machine(you need pay double way air tickets,salary,food,hotel for our engineer).

Double Colors Film Blowing Machine

Install machines in Saudi Arabia.

If you buy one container machines,we will pack machine with stretch film and loading container directly (FCL full container load).

Double Colors Film Blowing Machine

If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load(LCL).

Double Colors Film Blowing Machine

Our Main parts cooperator as following brand,but standard parts all made from China.

Double Colors Film Blowing Machine

How To Find Polyethylene For Blown Film Extrusion?
Extrusion Film Extrusion use Polyethylene,such as

Low Density Polyethylene(LDPE),High Density Polyethylene(HDPE) and Linear Low Density Polyethylene(LLDPE),Polypropylene(PP).
Below are big brand material supplier in the world,they open office all over the world,you can check them in local market.
1.Sabic Saudi Basic Industries Corporation
2.ExxonMobil Chemical Company
3.Dow Chemical Company

Double Colors Film Blowing Machine
